SQ(mm2) COMPOSITION CURRENT
(A)
0.05mm 0.08mm 0.18mm
0.1 3/17/0.05 3/7/0.08   1
0.3 3/51/0.05 3/20/0.08   5
0.5 3/85/0.05 3/33/0.08   8
0.75 7/55/0.05 3/50/0.08   10
1.25 7/91/0.05 7/36/0.08 7/7/0.18 15
2 7/146/0.05 7/57/0.08 7/12/0.18 20
3.5 7/255/0.05 7/100/0.08 7/20/0.18 30
5.5 7/406/0.05 7/157/0.08 7/31/0.18 45
8   7/228/0.08 7/45/0.18 55
10   7/284/0.08 7/57/0.18 60
14   7/399/0.08 7/79/0.18 65
16   7/454/0.08 7/90/0.18 70
22     7/124/0.18 75
25     7/140/0.18 80
30     7/168/0.18 90
35     7/197/0.18 105
38     7/214/0.18 115
50     19/104/0.18 150
60     19/125/0.18 185
70     19/145/0.18 210
80     19/166/0.18 245
100     19/207/0.18 300
